| Model | RC-D1030 | | Pick up Element | Color sony CCD | | Effective Picture Elements (H*V) | NTSC:976(H)X494(V);PAL:976(H)x582(v) | | Horizontal Resolution | 1000 TVL | | Efective pixels | 720 (H) X 480 (V) | | S/N Ratio | >50db | | Clock Frequency | NTSC:29.0699/ PAL:28.375 | | Scanning System | 2.1 interface | | Minimum Illumintaion | 0.001 Lux (with IR LRD ON ) | | Synchronous System | Internal Negative sync | | Auto Electronic Shutter | NTSC: 1/60s 1/100,000s,PAL:1/50s 1/100,000s | | Gama Characteristic | 0.45 | | IR Project Distance | 20 Meters (with 2u | | IR Status | Under 10Lux by CDS | | Video Output | 1Vpp,75 | | Auto Gain Control | Auto | | Power/Current | DV12V(+/-10%)250 mA | | Lens | 3,6 mm | | Storage Temperature | -30~+60° RH95% MAX | | Operating Temperature | -10~+45°C RH95% MAX |
|
