System | Main Processor | Hisilicon Hi3515 | System Resource | Sixfold operation: Live recording, Playback, Backup, Remote access, PTZ control, Mobile monitoring | Control Mode | Front panel, USB mouse, IR remote control, Keyboard, Network | Video | Input | 4×BNC, (1.0Vp-p,75Ω) | Standard | 4CH D1 real time ,NTSC: 120FPS, PAL:100FPS | Output | 1×BNC, (1.0Vp-p,75Ω) ,1×VGA | Audio | Input | 4×RCA | Output | 1×RCA | Display | Display Split | 01-abr | Resolution | VGA:1280*1024, 1024*768, 800*600 | Tour Display | Support | Recording | OSD | Camera title, Time, Video loss, Motion detection, Recording | Video/Audio | H.264/ADPCM | Image Resolution | D1(720*576/ 720*480), HD1(720*288/ 720*240), CIF(352*288/ 352*240) | Performance | 4D1 real time | Encoding stream | Main stream | D1; 100fps@PAL. 120fps@NTSC | Extra | CIF:20FPS | Recording Mode | Manual, schedule,Motion detection,Alarm | Recording Priority | Manual>Alarm> Motion detection | Video detection & Alarm | Trigger events | Recording, PTZ movement, Alarm, E-mail | Motion detection | Zones:396 (22*18) ,Sensitivity:1-5 (Level 5 is the highest) | Video loss | Support | Alarm | None | Playback & Backup | Playback channel | 4CH (4CH at the same time) | Playback speed | D1: 100fps@PAL, 120fps@NTSC | Search mode | Time/date, Alarm, Motion detection | Playback function | Play, Pause, Stop, Fast forward, Slow forward, Full screen etc. Recording files can be viewed by dragging the progress bar back and forth | Backup mode | U-disk /USB-HDD/ USB-CD /DVD-RW/Network | Network | Physical interface | RJ-45port (10/100M) | Network function | TCP/IP,UDP, DHCP, DNS,IP filter, PPPOE, E-mail, Alarm server, UPNP, DDNS,DNS Binding | Remote operation | Monitor, PTZ control, Playback, System setting, files download, Log information | Mobile Phone | Support Window Mobile, Symbian, Android, iPhone, Blackberry etc. | Hard Disk | Hard disk | 1 SATA port, the capacity of single hard disk MAX 2T | Space occupation | Audio: 14.4MB/H, Video: 56-900MB/H | HDD management | Hard disk hibernation technology, HDD faulty alarm, file restoration | Auxiliary Interface | USB | Two USB2.0 interface, for connecting mouse, U-disk, USB hard disk | RS485 | PTZ control | Environ-
ment | Power supply | 12V/3A | Working environment | -10ºC~+55ºC / 10~90%RH/ 86~106Kpa | Dimension | 250*235*45mm (Product size) | Weight | 2.0kg(W/O HDD);Package Weight:2.8Kg |
|
